How to install front coil springs without killing yourself!
« on: April 28, 2007, 03:14:53 PM »
Anybody who has ever tried installing coil springs on a car with no engine in it knows that putting them in can be a real challenge due to the fact that there isn't enough weight to hold the front of the car down. Here is how you do it easily and safely.  8)

#1  PREPARE YOUR WORK AREA
You want your control arms mounted to the frame and swinging freely. You want to have all your ball joints in and ready to go along with the nuts that go to them. You want your steering knuckles clean and ready to mount. You want to have a large chain to use as a safety chain. You will also need a coil spring compressor and a large socket wrench to turn it. Don't forget a floor jack and a pry bar.....and of course, those crazy coil springs. My coil spring compressor was purchased from National Parts Depot under part # 988-1 for $35.



#2   DROP IN THE COMPRESSOR AND MOUNT THE SPRING
A spring compressor usually comes with two ends that have hooks on them. One set of hooks slides freely up and down the long threaded rod and one actually screws onto the threaded rod. You need to remove the hooks that slide freely and set them aside. You want to use the hooks that screw up and down the rod.
Drop the threaded rod down through the upper shock hole in the subframe. Make sure you have a couple stout washers underneath the head of the bolt. Screw the threaded hooks onto the end of the rod.
If you are using the rubber spring isolators, attach them to the top of the spring now with plastic wire ties. Now mount the spring up into the subframe with the spring compressor going down through the center of the spring. Use the hooks to grab onto the spring at the lowest possible point. Make sure the threaded rod is centered in the spring. Make sure that the bottom end of the spring is rotated to the right spot so that when it's compressed it fits into the little pocket in the lower control arm correctly.  Now begin to tighten down the big long bolt just tight enough to hold the spring in. Once the spring is supported, use the safety chain to wrap through the bottom of the spring and around the subframe. This is a safety precaution just in case the spring compressor breaks or some other failure happens. These springs are very dangerous when compressed so do this EVERY time.




#3   COMPRESS THE SPRING
Once your safety chain is hooked up, you can begin to tighten the big threaded rod and compress the spring up into the subframe. Once you have it compressed enough to swing the control arm up high enough, attach the steering knuckle to the lower control arm ball joint. At this point you should slide the floor jack under the lower control arm and use it to hold the control arm tight against the bottom of the spring. Use a pry bar to pry the bottom of the spring into the spring pocket on the lower control arm. It will pry in very easily and pop right into place. Now use the floor jack to jack up the steering knuckle high enough to attach the upper ball joint. Once the ball joint nuts are tight, you can remove the safety chain.



#4 DECOMPRESS SPRING AND ADMIRE WORK
Once your ball joints are all attached and your steering knuckle is in and the safety chain is off, you can take out the floor jack and then loosen up the spring compressor to let the full tension of the spring out on the control arms. The spring compressor rod just pulls out the shock hole and the hooks just fall out the bottom hole. Pat yourself on the back....you got your coil springs in without maiming anybody!  :D

500cidstroker

  • Forum Member
  • *
  • Posts: 1
How to install front coil springs without killing yourself!
« Reply #1 on: July 29, 2007, 07:30:56 PM »
What brand of internal spring compressor did you use ? I have broken 3 internal ones . and I bought a set of the external ones but the spring will not go up in the frame pocket with them on the outside. I have tried to do it as you have shown and the threaded nut strips out after I get about 2 3/4 inches compressed . I have tried to compress the spring as shown by the tool maker with both coil ends on , and as soon as i get down to around 3 inches it broke . I need to get them compressed down from 16 inches to about 12 1/2 to fit in . The motor is out of the car so I can't use any jack under the a arm method .  I'm starting to wonder if the springs are to stiff.   I purchased them new from Ames and they were made by moog for a 78 with a/c , and with performance suspension (WS6) .The springs are about a half inch longer than the old ones , have the same outside diameter , the same coil thickness .  But the new ones have one extra wrap of coil versus the old .

glhx

  • Active Forum Member
  • *
  • Posts: 87
How to install front coil springs without killing yourself!
« Reply #2 on: September 25, 2007, 09:47:29 PM »
i used the spring compressor from napa and it worked realy well. Thank you for the post. It saved me alot of time and headache. My springs were only compressed down to 14 inchesand pry in the rest of the way.

L8KRFAN

  • Active Forum Member
  • *
  • Posts: 382
Re: How to install front coil springs without killing yourself!
« Reply #3 on: April 03, 2008, 09:33:03 AM »
Great info, but I wish I would have known about this last year when I did the suspension on my 71. Installing the coil springs was by far the most p.i.t.a. part of the install. I did it the old fashion way by compressing the spring with the same spring compressor you have but hoping the spring would not kill me! I also did not have the motor (or any front end sheet metal) in the car so the car would raise if I used the floor jack method.

Again, great post!
Los Angeles, California
-----------------------------------
1979 Trans Am Olds 403 Matching Numbers
1971 Camaro SS350 Matching Numbers

Rob

  • Active Forum Member
  • *
  • Posts: 624
  • patience & persistence
Re: How to install front coil springs without killing yourself!
« Reply #4 on: April 29, 2008, 08:10:55 PM »
you a pimp 4 this one thnx son  :-D

josephdrummerj

  • Forum Member
  • *
  • Posts: 1
Re: How to install front coil springs without killing yourself!
« Reply #5 on: June 06, 2008, 08:11:40 PM »
just had to say, great advice! im currently restoring my 1970 lemans sport and was kind of worried about installing the front springs. i was able to rent for free a coil spring compresser (thanks to living in a small town) and installed them just like you said. i did have the motor and trans in the car so that helped with the spindle install, but it still would have worked without it. i was able to get them in by myself, and yes without killing me! thanks for helping us shade tree mechanics and now my car is ready to rock!





Formula400

  • Active Forum Member
  • *
  • Posts: 47
Re: How to install front coil springs without killing yourself!
« Reply #6 on: June 14, 2008, 10:32:57 PM »
Thank you for this.  This was very helpful.

Biff1212

  • Active Forum Member
  • *
  • Posts: 253
Re: How to install front coil springs without killing yourself!
« Reply #7 on: August 23, 2008, 02:47:54 PM »
Thanks for posting this. I'm just starting this job and wondering the best way to attempt it. Great info. Thanks!
Jay
Calgary, AB
1977 4 speed W72

Biff1212

  • Active Forum Member
  • *
  • Posts: 253
Re: How to install front coil springs without killing yourself!
« Reply #8 on: September 09, 2008, 08:28:15 AM »
Great info Jason. I would like to share a tip that I used when I installed my springs. Instead of prying the spring into the lower control arm and using a floor jack, I used a couple of ratchet straps. One was hooked onto one of the lower coils and to the opposite side of the subframe and the other was on the lower control arm to the upper control arm once the spring was in position on the lower control arm. As I compressed the spring I tightened the ratchet strap attached to the spring to keep it inline with the lower control arm. Once the spring was compressed and the ball joints lined up the other strap was tightened to bring everything together. Worked like a charm!





Jay
Calgary, AB
1977 4 speed W72

jcurrieta

  • Active Forum Member
  • *
  • Posts: 269
  • The Car is done!!
      • "THE TRANS AM PROJECT"
Re: How to install front coil springs without killing yourself!
« Reply #9 on: November 03, 2008, 03:38:27 PM »
Few questions:
how hard is this exact method with the inner and outer fender still on?

also say i didnt use a compressor (my engine is in also) could one use the jack method with a safety chain of course to remove the springs?? Basicly when the lower arm (LCA) is supported and unbolted from the spindle (at the ball joint) does the LCA swing down far enoght to let the spring come out without it being compressed 1st?

'81 Trans Am 6.6L T-top (Y84 recreation) "SOLD"
'96 Trans Am LT1
'99 Dakota 4X4
'93 STS Cadillac

79trans-am

  • Active Forum Member
  • *
  • Posts: 14
  • 400 swap under way :)
Re: How to install front coil springs without killing yourself!
« Reply #10 on: January 06, 2009, 09:24:41 PM »
great info. i have been thinking about lowering my 79 T/A with ratial tuned supention. i was looking at the eibach kit with two front springs that lower it an inch. then just som new shocks out back and blocks of aluminum under the leaf springs to get the rear to sit a little lower also.
and advice or suggestions?
1979 T/A... Olds 403, Red on red w/ gold bird, and American Racing Outlaw 2 wheels--- Future= '73 400 swap w/6x-8 heads 'under way' (long way to go), 15x8 snowflakes (I'm cleaning and re-finishing), Macho T/A inspired silver/red paint-job, along with many other small projects with the car!

sinister76ta

  • Oracle Forum Member
  • *
  • Posts: 4200
  • -Christopher-
Re: How to install front coil springs without killing yourself!
« Reply #11 on: January 06, 2009, 11:29:17 PM »
I admire the amount of safety used in the pix and this tread. I was no where near as cautious when I did the springs in my 75 and 76, looking back I guess I should have been safer then using a gorilla bar and letting the springs fly(won't even mention the beer). I did however use the correct compression tool. I'm glad to see a safe instructive proceedure on removal and installation of coil springs.
73 Black Formula 400 4 speed
74 Admiralty Blue T/A 455 auto
75 Candy Apple Red Firebird 350 auto
76 Cameo White T/A 400 auto
76 Starlight Black T/A 455 4 speed
76 Sterling Silver T/A 400 4 speed
77 Glacier Blue Esprit 400 4 speed
81 Black Formula
75 Silver Formula parts car -dead-
76 Carousel Red T/A parts car -sold-
76 Trans Am parts car
78 Skybird parts car  -sold-

JacksTA

  • Active Forum Member
  • *
  • Posts: 138
Re: How to install front coil springs without killing yourself!
« Reply #12 on: April 17, 2009, 07:28:32 PM »
Installed both springs today in under 30 minutes, worked great, thanks for saving me grief. It's unreal how that shaft just fits in that hole, like it was made for it. I also used a plastic washer under the steel washer on the top so it didn't scratch the subframe at all. I did a 69 Camaro a few years back, and I don't think the hole was big enough to do it this way, and man was that rough. Thanks Jason, great stuff.

fixitrht

  • Oracle Forum Member
  • *
  • Posts: 1796
Re: How to install front coil springs without killing yourself!
« Reply #13 on: December 17, 2009, 02:40:13 PM »
I tried it this way just the other day and wow, it was so much easier than the prybar and dual spring compressors... great tip  and use the strap too, just not the small one in the pic... use a big one as these things are under pressure

My cars
77 400 4 SPEED W72 Y81 SE
73 455 4 SPEED TA Brewster (Waiting Restoration)
80 455 (Fun car)
87 GTA 5.7 (Driver)
71 Firebird (New Project)

vsefiream

  • Oracle Forum Member
  • *
  • Posts: 1587
  • Rochester, NY
      • 78 TransFormula Fire Am
Re: How to install front coil springs without killing yourself!
« Reply #14 on: January 20, 2010, 10:25:38 AM »
I just used this method last night.  It work very well!!  Best $35.00 I have spent yet.  I used the jack to lift the lower control arm and the spring popped into the pocket.
John R
1978 TransFormula Fire AM http://s491.photobucket.com/albums/rr273/vsefiream/My%20Fire%20Am/
1 of 815 4spd W72 formulas, now a TA clone, 461 stroker, DN 5spd, 4wd, full VSE stage I & II kits as well as some stage III items.  DSE sub frame connectors.

Rascal

  • Active Forum Member
  • *
  • Posts: 230
Re: How to install front coil springs without killing yourself!
« Reply #15 on: January 24, 2010, 10:16:33 PM »
But how do you take them off?
10th Anniversary T/A: 4-speed behind a 462

Beer, the cause and solution to all life's problems...

Chewey

  • Oracle Forum Member
  • *
  • Posts: 1544
Re: How to install front coil springs without killing yourself!
« Reply #16 on: January 25, 2010, 07:48:30 AM »
Same way, but reverse order, I just did this on my car. Put the bottom arms on the spring about 2 coils from the bottom so when you decompress the spring, it should be out of compression when the jaws reach the end of the 'jack screw'.

I would also buy some decent grade 8 washers for the jack screw. The ones that came with it are cheap and mine tore up.
« Last Edit: January 25, 2010, 07:50:36 AM by Chewey »
-mike

78 Trans Am 400 Auto (Dec 06 HPP)
76 Trans Am 455/4sp w/ t-tops (1 of 110)
02 Trans Am CETA Convertible M6 #1949



vsefiream

  • Oracle Forum Member
  • *
  • Posts: 1587
  • Rochester, NY
      • 78 TransFormula Fire Am
Re: How to install front coil springs without killing yourself!
« Reply #17 on: January 26, 2010, 10:09:38 AM »
Honestly, I don't recommend removing them the way I did.   Any hoo, I used an 8 foot section of rebar and threaded it down through the shock mounts in the frame and the lower control arm.  The car was in the air a few feet and the front clip & motor were removed.  I chained the spring to the frame & lower a-arm.  I stood inside the frame and removed the lower ball joint nut.  I believe I used a ball joint puller and seperated the ball joint with a long extension and a long handled ratchet.  It made a lot of noise when they popped but no drama.  The chain and rebar combo restricted the spring's motion.  It helped that there had been a coil cut off & flattened previously so the spring length (potential) wasn't as long.   Again I was in a hurry to pull the front end apart, it was late and I didn't have access to a spring compressor.  Stupid?  Yes.   Don't do it.
John R
1978 TransFormula Fire AM http://s491.photobucket.com/albums/rr273/vsefiream/My%20Fire%20Am/
1 of 815 4spd W72 formulas, now a TA clone, 461 stroker, DN 5spd, 4wd, full VSE stage I & II kits as well as some stage III items.  DSE sub frame connectors.

Rascal

  • Active Forum Member
  • *
  • Posts: 230
Re: How to install front coil springs without killing yourself!
« Reply #18 on: January 31, 2010, 11:24:41 AM »
Ok, getting ready to do this in about an hour, here are the steps I'm thinking

Removal:
chain on spring
install spring compressor, tension lightly
jack under a-arm
break ball joint
slowly lower a-arm - drop
spring is still tight against top - slowly loosen compression tool.
remove spring

Sound about right?

Don't know why I'm so nervous...
10th Anniversary T/A: 4-speed behind a 462

Beer, the cause and solution to all life's problems...

LeighP

  • Jedi Council
  • Oracle Forum Member
  • *
  • Posts: 19578
Re: How to install front coil springs without killing yourself!
« Reply #19 on: January 31, 2010, 01:52:11 PM »
sounds good...make sure that safety chain is in there and wrapped around the chassis. Watch your fingers, use pry bars if you need to, do not get your hands near these things......
Regards,
Leigh

Sydney, Australia
Former Firebirds -
1971 Pontiac Firebird 455
1977 Pontiac Trans Am
1976 Pontiac Trans Am
1967 Pontiac Firebird 400 convertible
1967 Pontiac Firebird 400 coupe


Rascal

  • Active Forum Member
  • *
  • Posts: 230
Re: How to install front coil springs without killing yourself!
« Reply #20 on: January 31, 2010, 02:49:19 PM »
Thanks Leigh.


Looks like I need to remove the swaybar from the lower A-arm too.  ?
10th Anniversary T/A: 4-speed behind a 462

Beer, the cause and solution to all life's problems...

LeighP

  • Jedi Council
  • Oracle Forum Member
  • *
  • Posts: 19578
Re: How to install front coil springs without killing yourself!
« Reply #21 on: February 01, 2010, 06:25:10 AM »
yep..sure do, or it can't drop enough.
Regards,
Leigh

Sydney, Australia
Former Firebirds -
1971 Pontiac Firebird 455
1977 Pontiac Trans Am
1976 Pontiac Trans Am
1967 Pontiac Firebird 400 convertible
1967 Pontiac Firebird 400 coupe


NomadTA

  • Active Forum Member
  • *
  • Posts: 68
Re: How to install front coil springs without killing yourself!
« Reply #22 on: January 03, 2011, 03:36:21 PM »
Good info. I'll know what to do when I put them back in. To get them out I removed the ball joint nuts and then whacked the outside of the upper ball joint portion of the spindle a couple of times and it let loose with a bang. Spring still can't get out though. I then used one part of the spring compressors that fit on the out side of the spring to compress it enough to slide it out. Gets the adrenaline moving, just stand inside the subframe and the spring can't get you. LOL
1970 Firebird, 04 Vette, 07 Av w/6" lift

LeighP

  • Jedi Council
  • Oracle Forum Member
  • *
  • Posts: 19578
Re: How to install front coil springs without killing yourself!
« Reply #23 on: January 03, 2011, 08:10:53 PM »
lol...you hope....they can bounce a long way!  :lol:
Regards,
Leigh

Sydney, Australia
Former Firebirds -
1971 Pontiac Firebird 455
1977 Pontiac Trans Am
1976 Pontiac Trans Am
1967 Pontiac Firebird 400 convertible
1967 Pontiac Firebird 400 coupe


NomadTA

  • Active Forum Member
  • *
  • Posts: 68
Re: How to install front coil springs without killing yourself!
« Reply #24 on: January 04, 2011, 10:52:59 AM »
lol...you hope....they can bounce a long way!  :lol:

Yep! The springs in my 70 wouldn't come out without compressing them even with the LCA all the way down. I won't be doing it that way again though! :)
1970 Firebird, 04 Vette, 07 Av w/6" lift

DeCaff2007

  • Oracle Forum Member
  • *
  • Posts: 2886
  • Radix Malorum Est Cupiditas.
Re: How to install front coil springs without killing yourself!
« Reply #25 on: February 04, 2012, 05:29:25 PM »
Yep.....  did this procedure today.  Just wanted to add that there are different types of internal compressors.  One has "arms" that are only a 90* angle from the hub on the screw shaft.  DO NOT use this kind!  It's a piece of garbage and the coil spring will come flying out when it's compressed.

The other type has arms that have the actual "hook".  This one will completely secure the coil spring while it's being compressed and is much safer.

Also, it does help to liberally grease the thread on the screw shaft and the two washers that are near the top of the screw shaft.  Makes turning it A LOT easier and will keep the threads from getting damaged.

I completely annihilated a spring compressor today because I made the mistake of NOT lubricating the threads.

Anyway, excellent write up!
1976 T/A 400 auto....
Check out my resto thread:  http://transamcountry.com/community/index.php?topic=48626.0

737driver

  • Oracle Forum Member
  • *
  • Posts: 1073
  • "Life is hard, It's Harder when your'e Stupid.."
      • My Trans Am - Restoration Project
Re: How to install front coil springs without killing yourself!
« Reply #26 on: May 22, 2013, 11:54:16 AM »
Great Information!
Just a quick question though, Is there a reason the area on the A arms by the ball joint are not painted, I am sending out my Sub-frame and Arms to get blasted and powder coated and was curious about the A arms being fully painted.
Thanks,
Jim
1979 Trans Am- Heritage Brown -W72 (Pontiac 400) -4Speed-WS6

Ag77T/A

  • Active Forum Member
  • *
  • Posts: 314
Re: How to install front coil springs without killing yourself!
« Reply #27 on: May 22, 2013, 12:15:28 PM »
Great Information!
Just a quick question though, Is there a reason the area on the A arms by the ball joint are not painted, I am sending out my Sub-frame and Arms to get blasted and powder coated and was curious about the A arms being fully painted.
Thanks,
Jim

The factory dipped the arms in paint but not the tip area with the ball joints. That area was left bare steel.

737driver

  • Oracle Forum Member
  • *
  • Posts: 1073
  • "Life is hard, It's Harder when your'e Stupid.."
      • My Trans Am - Restoration Project
Re: How to install front coil springs without killing yourself!
« Reply #28 on: May 22, 2013, 12:35:55 PM »
So does it make any difference whether that area is painted or not?
1979 Trans Am- Heritage Brown -W72 (Pontiac 400) -4Speed-WS6

Ag77T/A

  • Active Forum Member
  • *
  • Posts: 314
Re: How to install front coil springs without killing yourself!
« Reply #29 on: May 22, 2013, 02:35:52 PM »
I think it had more to do with cost of production/efficiency more than anything else.  I inquired about having it replicated when I had my arms powder coated but it was going to cost too much money for the type of build I'm doing so I just did the whole arm in one color.

NathanDK

  • Active Forum Member
  • *
  • Posts: 18
Re: How to install front coil springs without killing yourself!
« Reply #30 on: July 01, 2013, 02:27:52 PM »
This is how I did mine.

I used a length of 16mm threaded rod, a piece of square steel tubing with a piece of steel welded on it to add some strength, a piece of 1/2" steel water tubing as a spacer and some 16mm nuts. I installed the threaded rod thru the upper shock mounting hole, upper and lower A-arms, spring and square steel tube under the lower A arm. The 1/2" steel tubing is just a spacer to gain easier access to the nut that will need to be tightened to pull it all together. It went together without any problems. I used a cargo strap to pull the lower A-arm bushing into the frame mount, but it did not need much force applied to it at all. It just needed to be tilted a little. This method can also be used with the subframe in the car.





/Jesper

krackerjack79

  • Active Forum Member
  • *
  • Posts: 34
Re: How to install front coil springs without killing yourself!
« Reply #31 on: February 10, 2014, 05:37:08 PM »
The shocks have to be removed right?? Im about to tackle this project over the weekend Im taking the coil springs out then after I get all my new parts in then will have to reinstall,, also what about alignment?? any tricks on getting it close enough till you can get it to place that does alignments?

Ag77T/A

  • Active Forum Member
  • *
  • Posts: 314
Re: How to install front coil springs without killing yourself!
« Reply #32 on: February 10, 2014, 06:00:24 PM »
Yes, the shocks need to be removed to gain access to the inside of the coil spring and allow the arm to swing free.
If you are just replacing the bushings and not using the offset cross shafts then you should be able to put it back close to the alignment. Make sure you keep track of the shim stack on each bolt so you can reinstall them in the same position.

Here is a link to help you if you have access to an internal spring compressor:
http://transamcountry.com/community/index.php?topic=4042.0

I removed mine this way but installed them with a homemade compressor like the one shown in this thread.

GLTY


TammyTA

  • Active Forum Member
  • *
  • Posts: 89
Re: How to install front coil springs without killing yourself!
« Reply #33 on: August 02, 2014, 12:42:48 AM »
Mine wouldn't swing down enough either.  Was stupid and gave them a kick. Luckily they just fell out. Now to find that compressor.

Re: How to install front coil springs without killing yourself!
« Reply #33 on: August 02, 2014, 12:42:48 AM »
You can help support TAC!
